Mini Hydraulic Gear Pump High Pressure Gear Pump 21MPa 3200rpm Flat Key Shaft
USD 47.69 USD
Specifications
| *Feature* | good quality, durable |
| Hydraulic Pump Type | Hydraulic Gear Pump |
| Brand | Unbranded |
| Name | Hydraulic Pump-1A-6 |
| Sputum Volume | 6ml/r |
| Preset Pressure | 21MPa |
| Rated Speed | 1800rpm |
| Maximum Speed | 3500 rpm |
| Minimum Speed | 500 rpm |
| Volumetric Efficiency | 91% |
| Mechanical Efficiency | 88% |
| Flange Mounting Method | SAE standard |
| Input Shaft Connection Form | Flat Key |
| Inlet And Outlet Connection Type | Thread |
| Oil Inlet | PT3/8'' (BSPT 3/8'') |
| Oil Outlet | PT3/8'' (BSPT 3/8'') |
| Weight | 1.3KG |
| Type | Hydraulic Gear Pump |
| Pump Action | Single Acting |
Single Hydraulic Gear Pump Aluminum Alloy SAE Flat Key 6ML/R 21MPa. Simple installation and long service life, providing 21MPA pressure. 1PCS Hydraulic Gear Pump. Use flange mounting and use a flat key input shaft connection.
